Mirae Mx200 - Page 301

Linear Slide Check
Regular cleaning and
greasing
X-Y Gantry
4-22
Z-axis Nozzle Shaft Moving
Check
Check wear of spline and
bending of shaft.
Head
4-25
Z-axis Rack & Pinion check
Check greasing and
interval.
Head
4-27
R-axis Bearing check
Check wear of bearing and
bush.
Head
4-29
Timing Belt and Pulley check
Check wear of timing belt
and pulley.
Conveyor
4-31
Z-axis Linear Slide
Periodic cleaning and
greasing
Head
4-32
Air Filter check
Drain value open
Cover
4-33
Casting Off NG Part
Periodic cleaning
Conveyor
4-35
1500H
(Quarterly)
Lead Screw/Linear Slide
Periodic cleaning and
greasing
Conveyor
4-36
ANC
Check sensor attachment.
ANC
4-38
Timing Belt
Check wear and damage.
Conveyor
4-41
Timing Belt Tension
Adjust to a moderate
tension.
Conveyor
4-42
3000H
(Halfyearly)
Surface treatment on
exposed parts
Check corrosion on the
exposed surface.
X-Y Gantry
4-43
Board Transfer Belt(Ring
Belt)
Check wear and damage of
the ring belt.
Conveyor
4-44
Chapter 4 Regular Maintenance
3-3
Regular Checklist by Unit
Module
Item
Checking Point
Period
Ref
X-Y
Gantry
Abnormal noise check (after
running)
Check abnormal
noise/vibration.
24 Hours
4-6
Linear Scale Check
Check foreign materials on
the linear scale.
500 Hours
4-20
Linear Slide Check
Periodic cleaning and
greasing
500 Hours
4-22
Surface treatment on
exposed parts
Check corrosion on the
exposed surface.
3000
Hours
4-43
