4- 34 Mx-Series Manual
 Module: Head
<Module Head>
 Check Procedure
1.Unplug the machine.
2.Remove the head cover.
3.Check wear of the timing belt and pulley.
4.Since wear of timing belt and pulley may affect precision,
replace them if worn out. Contact the Mirae Customer Support
Team if the timing belt and pulley should be replaced.
Timing Belt
<
Belt Pulle
y
>
