Chapter 4 Regular Chec4k- 4-39
 Check and Greasing Procedure
1.Unplug the machine following the normal procedure.
2.Soak a clean cloth in denatured alcohol.
3.Wipe the Lead Screw, LM Guide and Ball Bush with a cloth soaked
in alcohol.
<
>
SINGLE CONVEYOR
>
<
DUAL CONVEYOR
Greasing
Ball bush
Greasing
LEAD
SCREW
Greasing
(
LM BLOCK)
LEAD SCREW
(
NUT-MOUNT)
