5-44 Mx-Series Manual
Inlet PCB Entrans Sen
2
st
’
Stopper Sen
Inlet Limit Sen
P_P Up/Dn Sen
Work Limit Sen
1
st
’
Stopper Sen
Outlet Limit Sen
Outlet Stopper Up Sen
Inlet Step Motor
Inlet ServoMotor
Work ServoMotor
WorkStep Motor
Outlet ServoMotor
Outlet Step Motor
