Mirae Mx200 - Page 417

Appendix E-7
O_R_FEEDERPKEY
KEY
1
10
r Feeder Key LED Output
OK / NG
O_R_FEEDERP
OT0111
1
11
r Feeder Control
Output(To=>SSR2)
OK / NG
I_STOPKEY
STOP KEY
0
12
f/r STOP Key Input
OK / NG
O_STOPKEY
1
13
f/r STOP Key LED Output
OK / NG
I_FDOORLOCK,
I_RDOORLOCK
DOOR
KEY
0
14
f/r DOOR Key Input
OK / NG
O_FOX_DOOR_LOCK
1
15
f/r DOOR Key LED Output
OK / NG
Notice:
1, I/O => Input = 0
Output = 1
2.Port 4,5 번 Part 회수용 OutletConveyor .(OPTION)
Mx100&200_NX12 I/O Check
Sheet
Draft ( )
Check ( )
Approval
(
Serial NO
Date
Signee
Description
Conveyor Step Motor Part &
SEMEMA
Examiner
Module No : 02
Address : A
Rev : 0
Revised date: 2007 / 11/ 24
Name
Label
I/O
Port
Description
Check
Remark
O_CHBEL1STA
TB CN1
1
0
Work Ent Conv_Belt Start Output
OK / NG
O_CHBEL1LOW
1
1
Work Ent Conv_Belt Low Speed
Output
OK / NG
O_CHBEL1MID
1
2
Work Ent Conv_Belt Middle Speed
Output
OK / NG
