Mirae Mx200 - Page 419

Appendix E-9
Description
LSM&SVEN Part
Examiner
Module No : 03
Address : B
Rev : 0
Revised date : 2007 / 11/ 24
Name
Label
I/O
Port
Description
Check
Remark
I_F_XLMTEMP
C/B CN2
0
0
Linear Motor Temp Signal #01
OK / NG
I_F_Y1LMTEMP
0
1
Linear Motor Temp Signal #02
OK / NG
I_F_Y2LMTEMP
0
2
Linear Motor Temp Signal #03
OK / NG
I_F_DOOR_LOCK
SN0303
0
3
f Door Sensor
OK / NG
O_F_DOOR_LOCK
F_DOOR
S/W
Sig
1
4
f Door Locking Signal
OK / NG
0
5
f Door System Sensor
OK / NG
I_R_DOOR_LOCK
SN0306
0
6
r Door Sensor
OK / NG
O_R_DOOR_LOCK
R_DOOR
S/W
Sig
1
7
r Door Locking Signal
OK / NG
0
8
r Door System Sensor
OK / NG
O_BULLAMP
OT0309
1
9
System Runing Lamp
OK / NG
SN0310
0
10
f_Floating Sensor
OK / NG
SN0311
0
11
r_Floating Sensor
OK / NG
O_LAMP
OT0312
1
12
Machine LAMP On/Off
OK / NG
I_AIRLOW
SN0313
0
13
Air Pressure Low Sensor
OK / NG
O_SVEN
P-BOX P1
1
14
SVEN (Servo Voltage Enable)
OK / NG
I_EMERGENCY
EMG
S/W(N.O)
0
15
Machine Emergency S/W Input
OK / NG
