Mirae Mx200 - Page 421

Appendix E-11
O_R_ANC_UNLOCK
SL0410
1
10
r ANC Lock/Unlock
Solenoid Valve
OK / NG
O_R_NBASE_UP
SL0411
1
11
r ANC Up/Dn Solenoid
Valve
OK / NG
P-ANC
O_CHBEL STA
CB CN 2
1
12
Outlet Conv_Belt Start
Output
OK / NG
OPTION
O_CHBEL LOW
0
13
Outlet Conv_Belt Low Speed
Output
OK / NG
OPTION
O_CHBEL MID
0
14
Outlet Conv_Belt Middle
Speed Output
OK / NG
OPTION
O_CHBEL DIR
0
15
Outlet Conv_ Belt Reverse
Output
OK / NG
OPTION
Notice :
1, I/O => Input = 0
Output = 1
2.12~15 Collectible Port Part Outlet Conveyor(OPTION)
Mx100&200_NX12 I/O Check
Sheet
Draft ( )
Check ( )
Approval
(
Serial NO
Date
Signee
Description
Front Trolley Part
Examiner
Module No : 05
Address : D
Rev : 0
Revised date : 2007 /10/ 04
Name
Label
I/O
Port
Description
Check
Remark
SN0500
0
0
f Trolley Feeder Base Down Sensor
OK / NG
SPARE0501
1
OK / NG
SN0502
0
2
f Trolley Feeder Base Set Position
S/W(Left)
OK / NG
SN0503
0
3
f Trolley Feeder Base Set Position
S/W(Right)
OK / NG
