E-16 Mx Series Manual
O_R_WORK_PHDN
SL0110
1
10
r Work Conv_Push Plate Down Solenoid
Valve
OK / NG
O_R_WORK1_STOP
SL0111
1
11
r Work Conv 1
ST
Main Stopper Solenoid
Valve
OK / NG
O_R_WORK2_STOP
SL0112
1
12
r Work Conv 2
ST
Main Stopper Solenoid
Valve
OK / NG
SL0113
1
13
OK / NG
SL0114
1
14
Inlet Stopper Up/Dn Solenoide Valve
OK / NG
SN0115
0
15
OK / NG
Notice :
1, I/O => Input = 0
Output = 1
2.D-CONV:Dual Conveyor
3.Port 12:Inlet Conveyor Stopper SOL
Mx400_NX12 I/O Check Sheet
Draft (
)
Check ( )
Serial NO
Date
Signee
Description
ANC&DOOR Sensor Part
Examiner
Module No : 02
Address : A
Rev : 0
Revised date : 2007 / 09/
14
Name
Label
I/O
Port
Description
Check
I_F_ANC_UNLOCK
SN0200
0
0
f ANC Unlock Sensor
OK / NG
I_F_ANC_LOCK
SN0201
0
1
f ANC Lock Sensor
OK / NG
I_F_NBASE_UP
SN0202
0
2
f ANC Up Sensor
OK / NG
I_F_NBASE_DN
SN0203
0
3
f ANC Dn Sensor
OK / NG
I_F_DOOR_LOCK
SN0204
0
4
f Door Sensor
OK / NG
