Mirae Mx200 - Page 428

E-18 Mx Series Manual
Name
Label
I/O
Port
Description
Check
O_BUZZER
System Lamp
1
0
Buzzer
OK / NG
O_REDLAMP
1
1
System Fault Lamp (Red)
OK / NG
O_GRNLAMP
1
2
System Running Lamp
(Green)
OK / NG
O_YELLAMP
1
3
System Error Lamp
(Yellow)
OK / NG
O_R_ANC_UNLOCK
SL0304
1
4
r ANC Lock/Unlock
Solenoid Val
ve
OK / NG
O_R_NBASE_UP
SL0305
1
5
r ANC Up/Dn Solenoid
Valve
OK / NG
I_F_FEEDERKEY
f_FEEDER
KEY
0
6
f Feeder Key Input
OK / NG
O_F_FEEDERPKEY
1
7
f Feeder Key LED
Output
OK / NG
1
8
f Feeder Control
Output(To=>SS
R1)
OK / NG
I_R_FEEDERKEY
r_FEEDER
KEY
0
9
r Feeder Key Input
OK / NG
O_R_FEEDERPKEY
1
10
r Feeder Key LED
Output
OK / NG
1
11
r Feeder Control
Output(To=>SS
R2)
OK / NG
I_STOPKEY
STOP KEY
0
12
f/r STOP Key Input
OK / NG
O_STOPKEY
1
13
f/r STOP Key LED
Output
OK / NG
I_FDOORLOCK,
I_RDOORLOCK
DOOR KEY
0
14
f/r DOOR Key Input
OK / NG
O_FOX_DOOR_LOCK
1
15
f/r DOOR Key LED
Output
OK / NG
Notice:
1, I/O => Input = 0
Output = 1
