Mirae Mx200 - Page 430

E-20 Mx Series Manual
Notice :
1, I/O => Input = 0
Output = 1
2.Ent,Ext Part=>Inlet,Outlet 적용시 공용
Mx400_NX12 I/O Check Sheet
Draft ( )
Check ( )
Serial NO
Date
Signee
Description
R_Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 11
Address : 9
Rev : 0
Revised date : 2007 / 09/
14
Name
Label
I/O
Port
Description
Check
O_BELT1STA
TB2 CN1
1
0
r Work Ent Conv_ Belt Start Output
OK / NG
O_BELT1LOW
1
1
r Work Ent Conv_ Belt Low Speed Output
OK / NG
O_BELT1MID
1
2
r Work Ent Conv_Belt Middle Speed
Output
OK / NG
O_BELT1DIR
1
3
r Work Ent Conv_ Belt Reverse Output
OK / NG
O_BELT2STA
1
4
r Work Conv_ Belt Start Output
OK / NG
O_BELT2LOW
1
5
r Work Conv_ Belt Low Speed Output
OK / NG
O_BELT2MID
1
6
r Work Conv_ Belt Middle Speed Output
OK / NG
O_BELT2DIR
1
7
r Work Conv_ Belt Reverse Output
OK / NG
O_BELT3STA
1
8
r Work Ext Conv_ Belt Start Output
OK / NG
O_BELT3LOW
1
9
r Work Ext Conv_ Belt Low Speed Output
OK / NG
O_BELT3MID
1
10
r Work Ext r Conv_Belt Middle Speed
Output
OK / NG
