A-6 C-Feeder User Manual
6. Move the reel and set the vinyl off point to the ‘Vinyl Off Slot’ of the reel cover.
7. Set the vinyl to go through the ‘Vinyl Off Slot’.
8. Adjust the reel to be engaged in ‘Feeding Gear’.
9. Adjust the ‘Shutter’ position, and close the ‘Reel Cover’. (Refer to the figure in Page 9.)
10. Set the vinyl from the ‘Vinyl Off Slot’ to be engaged in the ‘Vinyl Off Gear’.
11. Wind the ‘Vinyl Off Gear’ so that the vinyl gets tight. (Refer to the figure in Page 10.)
12. Use the ‘Manual Feeding Lever’ to have the chip placed before ‘Pickup Position’.
More than 200~250mm
To Next Page
