2-4 Trolley User Manual
No.
Name
Function
Remark
1
Frame
Supports arm and feeder base. Frame is transported with
the caster.
2
Handle
The operator grasps this part during the operation
3
Height adjusting bolt
Used to adjust height of trolley feeder base in accordance
with PCB height.
4
Vibration Feeder
Connector
Supplies power (24V) to the vibration stick feeder.
5
Feeder Base
The feeder is mounted on the feeder base. The feeder base
is on the trolley arm.
6
Interface Board
The controller that manages power supply and
communication between the machine and the feeder.
7
Feeder Base Bracket
Connects the feeder base with the arm. This part affects
accuracy feeder base location
8
Arm
Holds and connects the feeder base to the frame
9
In-position sensor dog
The dog mounted on the in-position sensor
10
Front/Rear Caster
Wheels for trolley movement. Turns 360 degree.
11
Reel Waste Basket
Collects the returned reels
12
Male Connector
The connector provides power supply/communication
between the interface board and the machine.
13
Guide Roller
Combined with the guide rail to provide forward/reverse
movement of trolley for trolley docking or disassembling.
14
Guide Hole
Connected with the guide pin of F/B block for precision
of positioning.
15
Urethane Stopper
Stops trolley when docking to the machine
