Mirae Mx200 - Page 542

2-6 Trolley User Manual
P40EX
Guide rail
Guide pin
Lift block
Female
co
nn
ec
to
r
Connector guide pin
Set-position sensor
In-position sensor
Connector up/down
cylinder
Feeder base block
Guide rail
In-position sensor
Guide pin
Lift block
Set-position sensor
Feeder base block
