Chapter 2 Parts and Functions 2-
9
No.
Name
Function
Remark
1
Guide-rail
Meets the guide roller when forwarding/reversing trolley
2
Guide-pin
Connected to the trolley guide hole to provide precision of
positioning.
3
Feeder base block
Frame of the feeder base block assy. The part supports the
feeder base bracket of the trolley to provide precision of
positioning.
4
Lift block
Lifts up the feeder base bracket of the trolley.
5
Connector Up-down
Cylinder
Actuator of female connector assy.
6
Connector guide pin
Guides connection between the female connector and the
male connector.
7
Female connector
Connected with the male connector of the trolley to
provide power supply/communication between interface
board and the machine.
8
In-position sensor
Detects trolley docking.
9
Set-position sensor
Detects contact between feeder base bracket and feeder
base block during trolley up action.
