Installation
RJ45 SignalStranded
element
Core colour Cable
designation
Pin Two-wire
connection
turquoise 3 x.2a
violet 6 x.2b
red 1 x.3a
green 2 x.3b
turquoise 7 x.4a
8
violet 8 x.4b
Prefabricated system cable 12 x RJ45
44
The cable is 6 m long and, at one extremity, has 12 RJ45 connectors for the interfaces on the front
panel. Two of them have 4 cores; the others, 2 cores. This means the cable is suitable for connecting the
following interfaces:
• 2 network interfaces BRI-T or 2 terminal interfaces BRI-S or a combination thereof.
• 10 terminal interfaces (DSI, FXS) or a combination thereof.
Note:
This cable cannot be used to connect PRI and Ethernet interfaces (see also Connection of PRI
primary rate interface and Connection of Ethernet interfaces).
44
Not valid for USA/Canada.
Release 7.1
System Manual for Mitel SMB Controller 106
