Installation
Parameter Parameter value
MAC address MAC address of the Ethernet NIC card. There are
four Ethernet ports (eth0 ... eth3), each having a
unique MAC address. lt;Model name>- lt;MAC-
Address>
Subnets
You can assign up to 10 subnets that can be assigned to any network interface. Make sure that the IP
address ranges of the different subnets are not overlapping.
Table 63: Subnets
Parameter Parameter Value
Interface A physical network interface from eth0-eth3.
Description Free text that is used for subnet configuration.
IP address IP address of the subnet.
Subnet mask Defines the range of an IP address, which are
available for this network.
Gateway IP address of the gateway.
Static routes for eth0
You can program Static IP routes, which belong to the network interface (eth0) interface.
Table 64: Static routes for eth0
Parameter Parameter value
Description Free text that is used for static routes.
IP address IP address of the static route.
Release 7.1
153 System Manual for Mitel SMB Controller
