FX-20P-E Handy programming panel Others Function 10
10-16
10.5.6 File register
• Set the number of blocks of the memory to be assigned to file registers. Up to 500 file
registers are available in each block. Out of the preset memory capacity, 500 steps is used
by each block.
• The allowable setting range in each PLC is as shown below.
FX
0
/FX
0S
Series PLC : File registers are not available. Set "0".
FX
1S
/FX
0N
Series PLC : 0 to 3 blocks
FX/FX
2C
Series PLC : 0 to 4 blocks
FX
1N
/FX
2N
/FX
2NC
Series PLC : 0 to 14 blocks
- In the allowable setting range shown above, input the
number of required blocks, then press the [GO] key.
10.5.7 RUN INPUT
•In the FX
1S
/FX
1N
/FX
2N
/FX
2NC
Series PLC, general-purpose inputs X000 to X017 can be
assigned as the RUN terminal.
- When using a general-purpose input as the RUN terminal,
place the cursor on "USE", enter the input No. (0 to 17), then
press the [GO] key.
- When not using a general-purpose input as the RUN
terminal, place the cursor on "DON’T USE", then press the
[GO] key.
FILE REGISTER
0 BLOCK
(ONE BLOCK = 500)
Display example
RUN INPUT
USE X000
DON'T USE
Display example
