5.6.2 Write NOP to entire range (program all clear)
Example: Entire range
• After the write function is set, consecutively press the [NOP] and [A] keys. At this time, the
cursor position has nothing to do with the write range.
• When the [GO] key is pressed, the message for confirming all clear is displayed.
Press the [GO] key in accordance with the message to execute batch write of NOP to the
entire range (program all clear).
When execution is completed, the cursor moves to the step No. 0.
W 100
101
102
103
NOPA
AND
OR
OUT
_
M1010
T 15
Y 012
All clear?
In the step 3)
W 0
1
2
NOP
NOP
NOP
OK
→
[GO]
NO
→
[Clear]
GO
NOP
A
GO
Display example
In the step 4)
In the step 5)
1)
2)
3)
4)
5)
Key operation
Write function
