FX-20P-E Handy programming panel Others Function 10
10-10
Parameter setting condition
• Set the PLC to the STOP status before changing parameters in the online mode.
• When using the EEPROM cassette, set the write-protect switch to OFF before changing
parameters in the online mode.
• When using the EPROM cassette, parameter change is disabled in the online mode.
10.5.2 Default setting
• Initialize the parameters.
- When setting the default values (initial values), place the
cursor on "YES" and press the [GO] key.
When not setting the default values, place the cursor on
"NO" (initial status) and press the [GO] key. By this
operation, the memory capacity setting screen appears.
PLC
status
RUN:
×
STOP:
✓
Valid memory Inbuilt memory:
✓
RAM cassette:
✓
EEPROM
cassette:
U
EPROM
cassette:
×
4.PARAMETER
DEFAULT SETTING?
YES NO
Display example
