FX-20P-E Handy programming panel Program Delete Operation 7
7-3
7.3 Batch delete of program by specifying range to be deleted
• The range of the program specified by step Nos. is deleted.
• If an instruction in the specified start step No. uses two or more lines, the head of the
instruction is regarded as the start step. If an instruction in the specified end step No. uses
two or more lines, the end of the instruction is regarded as the end step.
(In the example below, the end step No. is regarded as "42", not "40".)
• On the screen after the specified range is deleted, deleted steps are eliminated, and the
program is displayed from the deleted start step.
Basic operation
INS/
DEL
INS/
DEL
Delete function
STEP
Step No.
'
SP
STEP
Step No. GO
Specify the start step No. Specify the end step No.
Read
program.
