Appendix B:Major Key Operation List
Key operation example Description
HPP reset • [RST] [GO]
Resets the HPP (and displays the screen which is usually
displayed during startup).
Read
•[
↑
] / [
↓
]
Moves the cursor by 1 line at a time from the currently displayed
position.
• [GO] Scrolls the display by one screen.
• [Step] [1] [0] [GO]
Searches and displays the program by step No.
Press the [GO] key again to scrolls the program by one screen.
• [LD] [X] [1] [0] [GO]
Searches and displays the program by instruction
and device.
Press the
[GO] key
again to
search the
remaining
portion of
the program.
• [SP] [X] [1] [1] [GO] Searches and displays the program by device.
• [FNC] [1] [2]
Searches and displays an (16-
bit type) application instruction.
Pulse execution
(P) does not
have to be input.
• [FNC] [D] [1] [2]
Searches and displays an (32-
bit type) application instruction.
• [P] [0] [GO]
Searches and displays the program by label and
pointer.
