Mitsubishi FX-20P-E User Manual

FX-20P-E Handy programming panel
B-2
Write
Contact
instructions
• [LD] [X] [1] [0] [GO]
• [LDI] [X] [1] [1] [GO]
As to the LD, LDI, AND, ANI and ORI instructions, consecutively
input a device after a contact instruction.
• [LD] [P/I] [X] [1] [2]
[GO]
• [LD] [F] [X] [1] [3] [GO]
As to the LDP, LDF, ANP, ANF, ORP and ORF instructions, press
the [P/I] or [F] key after a contact instruction, then consecutively
input a device.
• [NOP] [P/I] [X] [1] [4]
[GO]
As to the INV instruction, press the [NOP] and [P/I] keys instead,
then consecutively input a device after that.
hikaku setten meirei Input it as an application instruction.
Block
instructions/
instructions
for storage
during
operation
• [ANB] [GO]
• [ORB] [GO]
• [MPS] [GO]
• [MRD] [GO]
• [MPP] [GO]
As to block instructions (ANB and ORB) and instructions which
store the intermediate result of the operation (MPS, MRD and
MPP), input only an instruction.
Drive
instructions
• [OUT] [Y] [2] [GO]
• [OUT] [T] [0] [SP] [K]
[1] [0] [0] [GO]
As to the OUT instruction for an output (Y), auxiliary relay (M) or
state (S), input a device after the instruction.
As to the OUT instruction for a timer (T) or counter (C), input a
device and set value after the instruction.
• [SET] [M] [1] [0] [0]
• [RST] [C] [1] [0]
As to the SET and RST instructions, input a device after an
instruction.
MC
instructions
• [MC] [0] [SP] [M] [1] [0]
[0] [GO]
• [MCR] [0] [GO]
As to the MC instruction, input the nesting level and device after
it. As to the MCR instruction, input the nesting level after it.
Key operation example Description
