Mitsubishi FX-20P-E User Manual

FX-20P-E Handy programming panel Write 5
5-2
Write operation condition
• When using the EEPROM memory cassette, set the write-protect switch to OFF.
5.2 Input of basic instruction
• Basic instructions are classified into those which are input individually such as "ORB" and
"MPS", those which are input together with a device such as "LD X000" and "AND M0" and
those which are input together with a device (first device) and set value (second device).
PLC
status
RUN:
×
STOP:
✓
Valid memory Inbuilt memory:
✓
RAM cassette:
✓
EEPROM
cassette:
U
EPROM
cassette:
×
GO
Basic operation
First device
GO
Input requiring only an instruction
Input requiring an instruction and device
'
SP
Input requiring an
instruction, first
device and
second device
GO
Second device
Instruction
Device
symbol
Write
function
Write
function
Write
function
Instruction
Instruction
Device
symbol
Device
No.
Device
No.
Device
No.
Device
symbol
