Mitsubishi FX-20P-E User Manual

Notes to Users 1
1-1
1. Notes to Users
1.1 Expression of this manual
In this manual, the term "program" indicates program, file register, comment and parameter
unless otherwise specified.
And the term "memory cassette" indicates memory cassette and memory board.
1.1.1 Expression of key operations
The following expression is used for each key operation.
.........Press the [A] or [B] key.
..........Press the [A] key, then the [B] key in this order (Numeric input etc.).
...............Press the [A] key, then the [B] key in this order.
............Press the [
↓
] key several times repeatedly.
.........While pressing and holding the [A] key, press the [B] key.
1.1.2 Expression of conditions
✓
: Usable
U
: Usable on conditions
×
: Unusable
PLC
status
RUN:
×
STOP:
✓
Valid memory Inbuilt memory:
✓
RAM cassette:
✓
EEPROM
cassette:
U
EPROM
cassette:
×
A B/
A B
↓
A
B
↓
+A B
FX-20P-E Handy programming panel

Mitsubishi FX-20P-E Specifications

General

Brand	Mitsubishi
Model	FX-20P-E
Category	Control Panel
Language	English
