Mitsubishi FX-20P-E - Memory Capacity

FX-20P-E Handy programming panel Others Function 10
10-11
10.5.3 Memory capacity
• Change the memory capacity.
- When changing the memory capacity, place the cursor on a
desired number of steps and press the [GO] key.
- The program capacity of each PLC is equivalent to less than
the number of steps shown below:
FX
0
/FX
0S
Series PLC : 800 steps (Select "2K STEP".)
FX
0N
/FX
1S
Series PLC : 2k steps
FX/FX
2C
Series PLC : 2k steps in the inbuilt RAM
8k steps maximum (including
comments and file registers)
as and when the memory
cassette is used
FX
1N
Series PLC : 8k steps
(including comments and file
registers)
FX
2N
/FX
2NC
Series PLC : 8k steps in the inbuilt RAM
16k steps maximum (including
comments and file
registers) when the memory
cassette is used
MEMORY SETTING
2K-STEP
4K-STEP
8K-STEP
Display example
16K-STEP
