FX-20P-E Handy programming panel Others Function 10
10-7
10.4.1 Transfer between memory cassette (online mode)
• Using the transfer function in the online mode, the user is capable of transferring programs
between the inbuilt PLC program memory and the attachable PLC memory cassette.
• The HPP automatically identifies the type of inbuilt PLC program memory and memory
cassette attached to the PLC.
• During the transfer from the inbuilt PLC program memory to the memory cassette, write is
enabled when RAM or EEPROM (write-protect switch set to OFF) type is identified. (If the
write-protect switch of the EEPROM is ON or if the EPROM is attached, the message
"WRITE FORBIDDEN" is displayed.)
Example: Transfer from the inbuilt PLC RAM to the EEPROM
• When transfer or collation is normally completed, the message "COMPLETED" is displayed.
• If a mismatch is detected by collation, the mismatch contents are displayed.
ONLINE MODE FX
1.OFFLINE MODE
2.PROGRAM CHECK
3.DATA TRANSFER
In the step 2)
Display example
1)
2)
3)
OTHER
Key operation
4)
Start up the HPP in
the online mode.
In the step 4)
3.DATA TRANSFER
FXRAM
→
EEPROM
FXRAM
←
EEPROM
FXRAM : EEPROM
3
GO5)
6)
GO
Select "DATA TRANSFER".
Or put the cursor on "DATA TRANSFER", then press the [GO]
key.
Select the transfer direction.
FXRAM
→
EEPROM: Write to the EEPROM attached to the PLC
FXRAM
←
EEPROM: Write to the inbuilt PLC RAM
FXRAM:EEPROM : Verify
.
.
