CPU MODULE PROCESSING TIME
11.1 Scan Time
11.1.2 Time required for each processing included in scan time
11 - 14
9
Parameters
10
Device Explanation
11
CPU Module Processing Time
12
Procedure for Writing Program to CPU ModuleAppendicesIndex
(d) Auto refresh of intelligent function module
This indicates the time taken to refresh data between the intelligent function
module buffer memory and CPU module devices.
Use the intelligent function module utility package (GX Configurator) to make auto
refresh settings.
Calculation method
Calculate the intelligent auto refresh time with the following expression.
(Refresh time) = KN1 + KN2 (number of refresh points)
Use the following values in Table11.10 for KN1 and KN2.
(Example)
When the number of auto refresh points for the analog-digital conveter module
(Q64AD) is 4 points (when the module is mounted on the Q01CPU main base
unit)
0.249(ms) = 0.085 + 0.041 4
Table11.10 When intelligent function module is mounted on main base unit
CPU module KN1 KN2
Q00JCPU
115 s 55 s
Q00CPU
91 s 46 s
Q01CPU
85 s 41 s
Q02CPU
53 s 13 s
Q02HCPU, Q06HCPU, Q12HCPU,
Q25HCPU, Q02PHCPU, Q06PHCPU,
Q12PHCPU, Q25PHCPU,
Q12PRHCPU, Q25PRHCPU
27 s 6 s
Q02UCPU
23 s 6 s
Q03UDCPU, Q03UDECPU
6s 5s
Q04UDHCPU, Q06UDHCPU,
Q13UDHCPU, Q26UDHCPU,
Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU, Q26UDEHCPU
4s 5s
Table11.11 When intelligent function module is mounted on extension base unit
CPU module KN1 KN2
Q00JCPU
120 s 56 s
Q00CPU
92 s 48 s
Q01CPU
86 s 43 s
Q02CPU
61 s 15 s
Q02HCPU, Q06HCPU, Q12HCPU,
Q25HCPU, Q02PHCPU, Q06PHCPU,
Q12PHCPU, Q25PHCPU,
Q12PRHCPU, Q25PRHCPU
29 s 8 s
Q02UCPU
45 s 7 s
Q03UDCPU, Q03UDECPU
7s 6s
Q04UDHCPU, Q06UDHCPU,
Q13UDHCPU, Q26UDHCPU,
Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU, Q26UDEHCPU
5s 6s
