28
4 Measurement Method
No. 99MAH056A
(Short press) / (Long press)
3 Press the [F2] key to reset the peak value and begin measuring.
» The selected peak detection display value is displayed.
For peak detection, start measurement with the contact point in contact with the
target to be measured.
Tips
• Be careful during measurement as displacement due to vibration or impact is also
detected.
• Peak detection will continue until the [F2] key is pressed again. To start a new peak
detection, press [F2] key to reset the peak value.
• The displayed values can be held during peak detection. For details, see
"4.5
Display Value Hold" on page 30.
• By switching the measurement mode to peak detection while holding, the amplitude,
maximum value and minimum value that are being held can be checked. While the
display value is being held, it will not switch to the current value display.
To Next Page
