No. 99MAH056A

5 Setting Parameters

(Short press) / (Long press)

1 Press the [F2] key.

» Calculation function can be set.

2 Setting the execution/stop of the calculation function

1 Press the [F1] key or [F3] key.

» Each time the key is pressed, it will switch execution/stop.

2 Press the [F2] key.

When execution [on] is selected:

» The calculation function display (A) blinks and the previously set calculation

coe󰀩cientisdisplayed.

Tips

Ifthedisplayedcalculationcoe󰀩cientiscorrect,pressthe[F2]key.Calculation

coe󰀩cientisconrmed;shiftstothenextparameteritem.

When stop [oFF] is selected:

» Selectionisconrmed;shiftstothenextparameteritem.

(Go to "5.8 Selecting Analog Bar Display" on page 56.)

3 Settingthecalculationcoe󰀩cient

1 Press and hold the [F2] key.

» The sign will blink and can be changed.

» Continue to 3 if not changing the sign.

2 Press the [F1] key or [F3] key.

» Each time the key is pressed, it will switch the sign.

3 Press the [F2] key.

» Thesignisconrmedandtheneighboringdigitblinks.

4 Press the [F1] key or [F3] key.

» Each time the key is pressed, the value will change by one.

5 Press the [F2] key.

» Thenumberisconrmedandtheneighboringdigitblinks.

» Each time the key is pressed, the blinking digit moves to the right.

Repeat steps 4 to 5aboveuntilthenumbersforalldigitsareconrmed

(e.g.: -6.4641).

» Conrmingthelastdigitwillcausethecalculationfunctiondisplay(A)toblink.

6 Reconrmthenumericalvaluesetandpressthe[F2]key.

» Calculationcoe󰀩cientisconrmed;shiftstothenextparameteritem.

(Go to "5.8 Selecting Analog Bar Display" on page 56.)
