Monarch NICE7000 - Parallel Control; Parameter Setting; Address Setting of Physical Floors

NICE7000 User Manual 5 System Commissioning and Functions
- 93 -
Function
Code
Parameter
Name
Setting Range
Setting in Parallel
Control
Setting in Group
Control
Fd-01
Elevator No. 1–8
1: master elevator
2: slave elevator
1: master elevator
2–8: slave elevator
Fd-02
Parallel/Group
control mode
0: Parallel control
Applicable to parallel
control of 2 elevators
2: Group control of
traditional mode
Applicable to group
control
The parallel/group control function has the following features:
•
When hall calls are registered, the system calculates the response time of the elevators
in parallel/group control in real time (based on distance, elevator arrival, door open/
close), and responds to all calls in the optimum way, minimizing the passenger waiting
time.
•
The elevators are congured as the master and slave ones. When they have the same
response conditions, the system instructs the master or slave to respond a call based
on the random function.
•
The parallel/group control function considers the call response time, elevator use
efciency, and in-car passenger waiting time. It avoids use ratio imbalance of elevators,
implements coordination between elevators to respond to hall calls and improves the
elevator use efciency.
The following part describes the parallel control and group control in detail.
1) Parallel control
•
Parameter setting
To use parallel control, connect the CAN2+ and CAN2- terminals of CN6 on the
controller to respectively the corresponding terminals on the other one.
The following table lists the parameter setting of parallel control.
Table 5-6 Parameter setting of parallel control
Function Code Parameter Name Setting Range Setting in Parallel Control
Fd-00
Number of elevators in
parallel/group mode
1–2 1–2
Fd-01
Elevator No.
1–2
1: master elevator
2: slave elevator
•
Address Setting of Physical Floors
Physical oor, relative to the NICE control system, is dened by the installation position
of the leveling plate.
The floor (such as the ground floor) at which the lowest leveling plate is installed
corresponds to physical oor 1.
The top physical oor is the accumulative number of the leveling plates.
