Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
44
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
4.2.1 Switching on control supply
2.
First only switch on the 24 V control supply for initializing and parameter-
izing. Do not yet switch on the AC mains supply.
Display reading after switching on the control supply
D1 D2 Action Explanation
Switching on the external 24 V control
supply
Initialization is running
Initialization completed Not ready for starting
Table 4.1 Switch-on status of the MSDServoDriveAC-AC (after connection of the 24 V DC
control supply)
NOTE: Details concerning the control supply can be found in section 3.7
“Connection of supply voltages“ starting at page26.
4.2.2 Connection between PC and servo drive
3.
The PC can be linked with the servo drive via USB or Ethernet (TCP/IP).
Connect PC and servo drive with the required connecting cable.
NOTES:
• Initialization
The communication link between PC and servo drive can only be set up
after the servo drive has completed the initialization.
• USB driver and TCP/IP configuration
If the PC does not recognize the connected servo drive you should check
the driver or the settings for the corresponding interfaces (see installation
manual Moog
DriveADministr Ator 5).
4.2.3 Parameter setting
4.
The Commissioning Wizard in MoogDriveADministrAtor 5 helps to make
settings to the drive system. Start the wizard.
NOTES:
• Help system
A detailed description of Moog
DriveADministr Ator 5 as well as the
commissioning wizard can be found in the Moog
DriveADministr Ator5 help
system.
• Motor dataset
If you intend to use a Moog servo motor, motor datasets are available.
4.2.4 Drive control with MoogDriveADministrAtor5
5.
Switch on the AC mains supply. Subsequently enable the power stage and
activate the servo drive. The drive should be tested without the coupled
mechanics.
DANGER CAUSED BY ROTATING PARTS! Danger to life from uncontrolled
rotation! Before starting motors with feather keys in the shaft end these
must be reliably secured against being ejected, as far as this is not already
prevented by drive elements such as belt pulleys, couplings or similar.
!
ATTENTION!
• Avoid damage caused by motor test run!
In this case it must be assured that the test will not cause any damage to
the system! Pay particular attention to the limitations of the travel range.
Please note that you yourself are responsible for safe operation.
Moog GmbH will not assume liability for any occurring damage.
• Destruction of motor!
