MSDServoDrive AC-AC Operation Manual
moog
64
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
A.2 Technical data MSDServoDriveAC-AC
A.2.1 G392-004A to G392-016, air-cooled
Designation
Technical data
G392-004A
G392-004
G392-006
G392-008
G392-012
G392-016
Output motor side
1)
Voltage 3-phase U
mains
Rated current effective (l
N
) 4A 4A 6A 8A 12A 16A
Peak current
see
Table A .1
see TableA.2
Rotating field frequency 0 ... 400Hz
Output stage switching
frequency
4, 8, 12, 16kHz
Input mains supply side
Mains voltage
1x 230V
±10%
(3x230V/ 3x400V/ 3x460V/ 3x480V) ±10%
Device connected load
1)
(with mains choke)
1.6kVA 2.8kVA 4.2kVA 5.9kVA 8.8kVA 11.1kVA
Current
1)
(with mains choke) 9.5A
2)
4.2A 6.4A 8.7A 13.1A 17.3A
Asymmetry of the mains voltage - ±3%maximum
Frequency 50/60Hz ±10%
Power loss at I
N
1)
85W 96W 122W 175W 240W 330W
1) Values related to a mains voltage of 3x400V
eff
(at G392-004A: 1x230V
eff
) and a switching frequency of 8kHz
2) without mains choke
3) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G392-xxx-xxx-xx2)!
Table A.7 Technical data G392-004A bis G392-016, air-cooled
Designation
Technical data
G392-004A
G392-004
G392-006
G392-008
G392-012
G392-016
DC link
Capacity 1740µF 400µF 725µF 1230µF
Brake chopper switch-on
treshold
1)
390VDC 650VDC
Minimum ohmic resistance of
an externally installed braking
resistor
3)
72 39 20
Brake chopper continuous
power
with external braking resistor
1)
2.1kW 5.9kW 11kW 21kW
Peak brake chopper chopper
with external braking resistor
1)
2.1kW 5.9kW 11kW 21kW
Optional:
internal braking resistor
PTC 90
Brake chopper continuous
power
with internal braking restistor
see section 3.15.2
Peak brake chopper chopper
with internal braking resistor
see section 3.15.2
1) Values related to a mains voltage of 3x400V
eff
(at G392-004A: 1x230V
eff
) and a switching frequency of 8kHz
2) without mains choke
3) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G392-xxx-xxx-xx2)!
Table A.7 Technical data G392-004A bis G392-016, air-cooled
NOTE: For further information on brake chopper switch-on threshold please
refer to chapter3.15.
