Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
70
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
A.3 Connections for motor cable
Characteristic
Size1 +
Size2
Size3 +
Size4
Size5
Size6 + Size6A
90 - 110A 143 - 170A
Connectivity for
cables (flexible
with ferrules)
0.25-4mm²
(AWG24 -
AWG10) *)
0.75-16mm²
(AWG18 -
AWG6)
maximum
25mm²
(AWG4)
35-95mm²
(AWG2 -
AWG4/0)
50-150mm²
(AWG3 -
AWG5/0)
Tightening
torque (Nm)
0.7 - 0.8 1.7 - 1.8 2.5-4.5 15-20 25-30
recommended
crimping tool
Phoenix
CRIMPFOX6
Phoenix
CRIMPFOX6
or 16S
Phoenix
CRIMPFOX
or similar
- -
*) Suitable for ferrules without plastic sleeve up to 6mm²
Table A.13 Technical data terminals for motor cable Size1 to Size6A
Characteristic Size7
Screws for ring terminal end
ZK-, ZK+, RB-, RB+: M10
L1-3, U, V, W: M12
Tightening torque (Nm)
Screws M10: 20-25
Screws M12: 25-30
Table A.14 Technical data for connecting bars for motor cable Size7
A.4 Current demand of control supply
Housing variant Size
maximum starting cur-
rent
Continuous current
Air cooling
Size1 - Size4 6A 2A
Size5 7A 2.5A
Size6 - Size6A 10A 0A (10A)
1)
Liquid cooling
Size3 - Size4 6A 2A
Size5 7A 2A
Size6 - Size6A 8A 0A (2A)
1)
Size7 4A 2A
1) The value in brackets is valid as long as the voltage supply for the power section is switched off. Once the power section is
supplied with voltage, an internal high-voltage switch-mode power supply will take over the supply for the control unit..
Table A.15 Current demand of control supply
A.5 Ambient conditions
Ambient conditions MSDServoDriveAC-AC
Degree of protection IP20 except the terminals (IP00)
Accident prevention instructions
according to local regulations
(in Germany e.g. SizeVA3)
Mounting height
up to 1000 m above sea level, higher than 1000 m above
sea level with reduced power 1% per 100m, maximum
2000m above sea level
Pollution severity 2
Type of installation
Built-in unit, only for vertical installation in a control cabinet
with minimum degree of protection IP4x, when using the
safety function STO minimum IP54.
Table A.16 Ambient conditions MSDServoDriveAC-AC
