MSDServoDrive AC-AC Operation Manual
moog
71
[ Appendix ]
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
Climatic conditions MSDServoDriveAC-AC
during
transport
acc. to EN61800-2, IEC60721-3-2 class 2K3
1)
Temperature -25 to +70 °C (-13 to +158 °F)
Relative air humidity 95% at maximum +40°C (+104°F)
during
storage
acc. to EN61800-2, IEC60721-3-1 class 1K3 and 1K4
2)
Temperature -25°C to +55°C (-13 to +131 °F)
Relative air humidity 5 to 95%
during
operation
acc. to EN61800-2, IEC60721-3-3 class 3K3
3)
Temperature
Air
cool-
ing
Size1
-10°C to +45°C (+14 to +113 °F) (4kHz)
-10°C to +40°C (+14 to +104 °F) (8, 12, 16kHz)
Size2 to Size4
-10°C to +45°C (+14 to +113 °F) (4kHz), up to +55°C
(+131 °F) with power reduction (5% per °C/°F)
-10°C to +40°C (+14 to +104 °F) (8, 12, 16kHz), up to
+55°C (+131 °F) with power reduction (4% per °C/°F)
Size5 to Size6A
-10°C to +45°C (+14 to +113 °F) (4kHz)
-10°C to +40°C (+14 to +104 °F) (8, 12, 16kHz), above
up to +55°C (+131 °F) with power reduction
(2% per °C/°F)
Liquid
cool-
ing
Size3 and Size4
-10°C to +45°C (+14 to +113 °F) (4kHz), up to +55°C
(+131 °F) with power reduction (5% per °C/°F)
-10°C to +40°C (+14 to +104 °F) (8, 12, 16kHz), up to
+55°C (+131 °F) with power reduction (4% per °C/°F)
Size5 to Size6A
-10°C to +45°C (+14 to +113 °F) (4, 8, 12, 16kHz), up to
+55°C (+131 °F) with power reduction (2% per °C/°F)
Size7
-10°C to +40°C (+14 to +104 °F) (2, 4kHz), up to
+55°C (+131 °F) with power reduction (2% per °C/°F)
Relative air humidity 5 to 85% without Condensation
1) The absolute air humidity is limited to maximum 60g/m³. This means e.g. at +70 °C (+158 °F), that the relative humidity must
only be maximum 40%.
2) The absolute air humidity is limited to maximum 29g/m³. The maximum values for temperature and relative air humidity
specified in the table must not occur at the same time.
3) The absolute air humidity is limited to maximum 25g/m³. This means, that the maximum values for temperature and relative
air humidity specified in the table must not occur at the same time.
Table A.17 Climatic conditions MSDServoDriveAC-AC
Mechanical conditions MSDServoDriveAC-AC
Vibration limit during
transport
acc. to EN61800-2, IEC60721-3-2 class 2M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 3.5 not applicable
9≤f<200 not applicable 10
200≤f<500 not applicable 15
Shock limit during
transport
acc. to EN61800-2, IEC60721-2-2 class 2M1
Dropping height of packed device maximum 0.25m
Vibration limits of
system
1)
acc. to EN61800-2, IEC60721-3-3 class 3M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 0.3 not applicable
9≤f<200 not applicable 1
1) Note: The devices are solely intended for stationary use.
Table A.18 Mechanical conditions MSDServoDriveAC-AC
!
ATTENTION!
• Control cabinet minimum IP54 for STO
According to EN ISO 13849-2 the control cabinet must have degree of
protection IP54 or higher when using the safety function STO (Safe Torque
OFF).
• No continuous vibrations!
The servo drives must not be installed in areas where they would be
permanently exposed to vibrations.
