Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
67
[ Appendix ]
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
A.2.4 G395-016 to G395-070, liquid-cooled
Designation
Technical data
G395-016
G395-020
G395-024
G395-032
G395-053
G395-070
Output motor side
1)
Voltage 3-phase U
Net
Rated current effective (l
n
) 16A 20A 24A 32A 53A 70A
Peak current see Table A.4 see Table A.5
Rotating field frequency 0 ... 400Hz
Output stage switching
frequency
4, 8, 12, 16kHz
Input mains supply side
Mains voltage (3x230V/ 3x400V/ 3x460V/ 3x480V) ±10%
Device connected load
1)
(with mains choke)
11.1kVA 13.9kVA 16.6kVA 22.2kVA 37kVA 50kVA
Current
1)
(with mains choke) 17.3A 21.6A 26.2A 34.9A 53A 70A
Asymmetry of the mains voltage ±3%maximum
Frequency 50/60Hz ±10%
Power loss at I
N
1)
330W 400W 475W 515W 690W 930W
1) Values related to a mains voltage of 3x400V
eff
and a switching frequency of 8kHz
4) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G395-xxx-xxx-xx2)!
5) Cooling power sufficient even with optional internal braking resistor
Table A.10 Technical data G395-016 to G395-070, liquid-cooled
Designation
Technical data
G395-016
G395-020
G395-024
G395-032
G395-053
G395-070
DC link
Capacity 1230µF 2000µF 430µF 900µF
Brake chopper switch-on treshold 650VDC
1)
820VDC
Minimum ohmic resistance of
an externally installed braking
resistor
20Ω 12Ω 10Ω
4)
Brake chopper continuous
power with external braking
resistor
21kW 35kW 67kW
Peak brake chopper chopper
with external braking resistor
21kW 35kW 67kW
Optional:
internal braking resistor
- 20 10
Brake chopper continuous
power with internal braking
resistor
- 675W 1350W
Peak brake chopper chopper
with internal braking resistor
- 34kW 67kW
Cooler data
Coolant pressure
(nom. value / maximum value)
1 / 2bar
Coolant flow
5)
(nom. value / maximum value)
3 / 4l per min 8 / 11l per min
Feed coolant temperature
The coolant temperature can be between +5 °C (+41 °F) and
+40 °C (+104 °F). However, the coolant temperature should
not be more than 10 °K below the ambient temperature, to
avoid moisture condensation on the heat sink.
1) Values related to a mains voltage of 3x400V
eff
and a switching frequency of 8kHz
4) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G395-xxx-xxx-xx2)!
5) Cooling power sufficient even with optional internal braking resistor
Table A.10 Technical data G395-016 to G395-070, liquid-cooled
