MSDServoDrive AC-AC Operation Manual
moog
72
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
A.6 Mains filter
Details to the subject "Electromagnetic Compatibility” can be found in section 3.1
"Notes for installation“ starting from page17.
The following table shows the permissible motor cable lengths in accordance with the
standard EN 61800-3.
Servo
drive
4 kHz
power stage
cycle frequency
8 kHz
power stage
cycle frequency
12 kHz
power stage
cycle frequency
16 kHz
power stage
cycle frequency
Categorie
C3 C2 C3 C2 C3 C2 C3 C2
G392-004A
1)
G392-004
1)
40m 20m 40m 15m 40m 10m 40m 8m
G392-006
1)
40m 20m 40m 15m 40m 10m 40m 8m
G392-008
1)
40m 20m 40m 15m 40m 10m 40m 10m
G392- 012
1)
40m 20m 40m 15m 40m 10m 40m 10m
G392-016
1)
G395-016
1)
40m 10m 40m 10m 40m 10m 40m 10m
G392-020
1)
G395-020
1)
40m 10m 40m 10m 40m 10m 40m 10m
G392-024
1)
G395-024
1)
40m 10m 40m 10m 40m 10m 40m 10m
G392-032
1)
G395-032
1)
40m 10m 40m 10m 40m 10m 40m 10m
G392-045
2) 3)
G395-053
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G392-060
2) 3)
G395-070
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
C3 = "Second environment" (industrial area)
C2 = "First environment" (residential area)
1) The motor shield terminal is not on the plate screen, but directly on the device terminals.
2) For compliance with the standard mains chokes (uK = 4 % to 32 A / uK = 2 % at 45 to 450 A) must be used
3) Compliance with the standard is only possible when using an external filter (no internal filter present)
Table A.19 Permissible motor cable length
Servo
drive
4 kHz
power stage
cycle frequency
8 kHz
power stage
cycle frequency
12 kHz
power stage
cycle frequency
16 kHz
power stage
cycle frequency
Categorie
C3 C2 C3 C2 C3 C2 C3 C2
G392-072
2) 3)
G395-084
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G392-090
2) 3)
G395 -110
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G392-110
2) 3)
G395-143
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G392-143
2) 3)
G395-170
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G392-170
2) 3)
G395-210
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G395-250
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G395-375
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
G395-450
2) 3)
25m 10m 25m 10m 25m 10m 25m 10m
C3 = "Second environment" (industrial area)
C2 = "First environment" (residential area)
1) The motor shield terminal is not on the plate screen, but directly on the device terminals.
2) For compliance with the standard mains chokes (uK = 4 % to 32 A / uK = 2 % at 45 to 450 A) must be used
3) Compliance with the standard is only possible when using an external filter (no internal filter present)
Table A.19 Permissible motor cable length
