MSDServoDrive AC-AC Operation Manual
moog
52
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
4.4.6 Firmware update with MMC-card
The MMC-card can be used to perform a Firmware update for the MSDServoDrive
AC-AC. For this purpose the HEX-file of the Firmware to be updated with the file name
“main.hex” must be copied into the directory “\Firmware\” in the root directory of the
MMC-card.
The MMC-card prepared in this way must then be inserted into the MSDServoDrive
AC-AC. Subsequently reset the 24 V DC control supply, while holding both buttons (T1
and T2) depressed at the same time. Once the display shows the code “c1” you may
release both buttons.
The progress of the Firmware update appears in the display in form of a flashing dot
after D2 and in succession with “c1” ... “c4”. After a successful update the new Firmware
will perform as usual. In case of an error the code “cE” will be displayed. In this case you
must reset the 24 V DC control supply and repeat the download process.
