Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
22
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
3.4 Overview of connections Size7
The following shows the layout with the corresponding positions of plugs and terminals.
For better orientation we have identified the designations of plugs and terminals with an
abbreviation.
Fig. 3.6 Layout Size7 (here without plate screens and terminal covers on X11 and X12)
X11
X45
D1, D2
T1, T2
X2
SW
HW
X12
X44
X8
X7
X6
X1
X3
X4
X5
Option1
