Moog G392-004 User Manual

MSDServoDrive AC-AC Operation Manual
moog
68
Id. no.:CA65642-001 Date:03/2012
to the glossaryto the table of contents
A.2.5 G395-084 to G395-210, liquid-cooled
Designation
Technical data
G395-084
G395-110
G395-143
G395-170
G395-210
Output motor side
1)
Voltage 3-phase U
Netz
Rated current effective (l
n
) 84A 110A 143A 170A 210A
Peak current see Table A.5
Rotating field frequency 0 ... 400Hz
Output stage switching
frequency
4, 8, 12, 16kHz
Input mains supply side
Mains voltage (3x230V/ 3x400V/ 3x460V/ 3x480V) ±10%
Device connected load
1)
(with mains choke)
58kVA 76kVA 99kVA 118kVA 128kVA
Current
1)
(with mains choke) 84A 110A 143A 170A 185A
Asymmetry of the mains voltage ±3%maximum
Frequency 50/60Hz ±10%
Power loss at I
N
1)
1130W 1500W 1940W 2380W 2650W
1) Values related to a mains voltage of 3x400V
eff
and a switching frequency of 8kHz
4) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G395-xxx-xxx-xx2)!
5) Cooling power sufficient even with optional internal braking resistor
Table A.11 Technical data G395-084 to G395-210, liquid-cooled
Designation
Technical data
G395-084
G395-110
G395-143
G395-170
G395-210
DC link
Capacity 900µF 2120µF 4240µF
Brake chopper switch-on treshold 820VDC
Minimum ohmic resistance of
an externally installed braking
resistor
10Ω 12Ω 10Ω 8.5Ω 6.5Ω
Brake chopper continuous
power with external braking
resistor
67kW 56kW 67kW 79kW 103kW
Peak brake chopper chopper
with external braking resistor
67kW 56kW 67kW 79kW 103kW
Optional:
internal braking resistor
10 7.5 5
Brake chopper continuous
power with internal braking
resistor
1350W 2650W 4000W
Peak brake chopper chopper
with internal braking resistor
67kW 90kW 135kW
Cooler data
Coolant pressure
(nom. value / maximum value)
1 / 2bar
Coolant flow
5)
(nom. value / maximum value)
8 / 11l
per min
11 / 13l per min
Feed coolant temperature
The coolant temperature can be between +5 °C (+41 °F) and
+40 °C (+104 °F). However, the coolant temperature should
not be more than 10 °K below the ambient temperature, to
avoid moisture condensation on the heat sink.
1) Values related to a mains voltage of 3x400V
eff
and a switching frequency of 8kHz
4) Connection of an ext. braking resistor is not permitted for devices with int. braking resistor (version G395-xxx-xxx-xx2)!
5) Cooling power sufficient even with optional internal braking resistor
Table A.11 Technical data G395-084 to G395-210, liquid-cooled
