Morgana Digifold Pro CB - 6. Upper Input Roller - Setting the Parallelism & Pressure

Page51
6.UpperInputRoller-SettingtheParallelism&Pressure
TheUpperInputRollerisgeardrivenfromtheLowerInputRoller&shouldbeadjustedfor
parallelism&pressuretoensuresheetsarecorrectlyalignedandcontrolled
OntheLaysideendofthisroller,thereisaneccentrichousingwhichenablesadjustment.
ThehousingissecuredtotheshaftusingtwoM5flattipsetscrews.
LoosenthetwoOperatorsideHousingscrews(M5setscrews)&inserttwo80gsm
teststrips(oneeachend)intothenipoftheInputRollers.
.
6.1.
FIG.6.1.A
OpSideHousing
M5CapHeadScrew
RadialSlot
UpperInputRoller
LaysideEccentricHousing
LaysideHousingSetScrews(M5)
