6.2.
6.3.
6.4.
6.5.
6.6.
AdjusttheLaysideHousing,usingtheshaftflatsontheoperatorside,untilalight
pressureisfeltontheoperatorstrip&thentemporarilytightenoneofthehousing
setscrewsontheopside.(thetopone).
Nowadjusttheoperatorsidehousing,usingtheM5capheadscrew,togiveavery
light'pull'ontheteststrips&tightentheoperatorsidesecuringscrew
(anM5capheadscrewintheradialslotintheedgeoftheOperatorSidePlate)
Checkthe'feel'onacompleterotationoftherollertoensuretherollerisconcentric
&repeatfrom6.2untilbothstripshavethesame(verylight)feelontheteststrips.
Finally,tightenbothoftheopsidehousingscrews(M5setscrews).
Now,usingtheoperatorsidesecuringscrew,(theM5capheadscrewintheradial
Slot)adjustthewholerollerassemblytogiveaheavypullontheteststrips.
(SeeFIG.6.1.A).
Re-tightentheoperatorsidesecuringscrewandre-check.Repeatuntilparallel.
FIG.6.1.B
80gsmTestStripsShaftFlats
CREASING/FOLDING
