8.PerforatorAssembly
14
25
3
ThePerforatorAssemblyalsoactsasanoutfeedunittoensurethatsheetsaresuccessfully
ejectedontothedelivery.Itisgeardrivenoffthe3rdFoldRollerandheldinpositionbyaGas
Strut.(Theassemblycanbeswungawayfromthepaperpathtomakeclearingpaperjams
easier.
Theonlyadjustmentsaretothegearmesh,parallelism,andpositionofthePerforatorDrive
Wheels&Hubs.
LowertheDeliveryUnit&swingthePerforatorAssemblydowntoitslowestposition.
Usinga2mmA/FHexagonKey,loosentheM4GrubScrewineachoftheWheels&
Hubs()andarrangethemasshownbelow.
TherecommendedpositionsoftheWheelsandHubsaredifferentwhenFoldingorPerfing.
-Perforatingdrivewheelwithmountedblades-Drivehubwithmountedanvils
-Perforatorstripper-Standarddrivehub
-Standarddrivewheel
8.1.
8.2.
10Positions
Note:-
WHEEL&HUBARRANGEMENT,(WHENFOLDING) WHEEL&HUBARRANGEMENT,(WHENPERFING)
1
2
3
4
5
Page56 CREASING/FOLDING
