6.2.2.5.Whilstholdingthebeltawayfromthepulleycarefullyrotatethepotentiometer
pulleyuntilitreachestheendofitstravel.
16.2.2.6.Continuetoholdthebeltawayfromthepulleyandrotatethepotentiometer
pulleyintheoppositedirectionforafull5turns(useamarkforreferenceif
required).
16.2.2.7.Re-engagethebeltwiththispulley,andre-tensionthebelt.
16.2.2.8.TightenthetwoM5Capheadscrewstosecurethepotentiometerbracket.
16.2.2.9.Re-fittheundersidecover.
.
