16.2.2.
Topositiontherollercorrectlythereisapotentiometerwhichprovidesthefeedbacktothe
processor.Inordertosetthiscorrectly,youmustfollowthisprocedure;
16.2.2.1.Raisethedeliveryuntilitisfullyup.
16.2.2.2.RemovethefourM4PanHeadscrewsfromthe'UndersideCover',remove
thiscover.
DeliveryPotentiometer
FIG.16.2.2.4
M5CapHead
Screws
Potentiometer
Pulley
Potentiometer
Belt
FIG.16.2.2.2
M4PanHeadScrews
UndersideCover
CREASING/FOLDING
16.2.2.3.Slidethe'DeliveryRoller'tothemid-pointofthedeliverybelt.
16.2.2.4.LoosenthetwoM5capheadscrewssecuringthepotentiometerbracketto
enableittoslide.
