Page69
The'DeliveryRoller'drivebeltsneedtobetensionedcorrectly(seeprevioussection).
-WhenadjustingthetensionoftheLaySide'DeliveryRollerDriveBelt',noticethatyou
arealsoprovidingthetensionforthemotordriveforthisroller.
Oncethebeltsaretensionedcorrectly,youneedtochecktoseeiftherollerislocatedequally
onbothsides.Youcancheckthisbymovingtherollerbyhandtooneendandcomparingthe
slidingbracketpositionstotheslotsonthesidepanelsofthedelivery.Iftheyarenotequal,the
laysidemustbeadjustedusingthefollowingmethod;
Lowerthedeliveryuntiltheunitisvertical.
Removethe4fixingscrewsfromthe'UpperEndPanel'and
Removethispanel.(SeeFIG.16.1.2).
Onthedeliverybeltrollershaftthereisapulleyonthelayside.Loosen
thetwoM4securingsetscrewsandrotatethepulleytore-alignthetwo
sidesofthedeliveryroller.
.
16.2.1.4.Re-tightenthesecuringscrewsofthepulley
NOTE
DeliveryRollerSquareness16.2.1.
16.2.1.1.
16.2.1.2.
16.2.1.3.
FIG.16.2.1.3
Pulley
DigifoldPro
SYSTEM
