Morgana Digifold Pro CB - Page 86

Page86 CREASING/FOLDING
WhenyoureleasetheE-stopswitch,thecontrolsystemshouldreceivepowerandbeginto
boot-up.Afterashortperiodoftimeyouwillseethetouchscreenbecomeactiveanddisplay
theboot-upsequence.
Ifthetouchscreenremainsblank,checkthatthereismainspowertothemachineandtothe
E-stopswitch,thenusetheRAPthatfollows.
IstherepowertotheATXPSU?
CheckthatthereisVACacrosstheATXPSUpowercord.
IdentifyreasonfornopowertoATXPSU.
Check500mAfuse,belowtheMainsInputconnector(SeePage90).
Ifthisfusehasblownreplaceitmustbereplacedwitha
T500mAfuse,Morganapartnumber681-020.
IsthereaVDCoutputfromtheATXPSU?(Seepage84).
ReplacetheATXPSU.
Doesthecoolingfanrunonthemini-ITXmotherboard?(Seepage84).
Replacethemini-ITXmotherboard.
IsthereaVDCpowertotheTouchscreen?
Repairthewiringconnection.
ReplacetheTouchscreenAssembly.
FAULT:-NoTouchscreenDisplay,(Machinewillnotbootup).
IMPORTANT.
•
•
YesNo
YesNo
YesNo
YesNo
