Note: Any unused bits will be set to zero and will be ignored by the receiving entity.

<pages> Total number of pages

<mr> Message Reference

<ra> Message Recipient address

<tora> Type of Recipient address

<scts> Service center time stamp

<dt> Discharge-Time

<st> Status

Table 3-56: Layout of SMS-DELIVER in PDU Mode (according to GSM03.40)

Reference Description Length

<sca> Service Center address:

1 BYTE: length (number of followed

octets).

Mandatory

1 BYTE: <tosca> - value between

128-255

1, 3-12 BYTES

(When length is 1, length BYTE = 0 )

<fo> First Octet. See Table 3-57.1 BYTE

<TP-OA> Originating address formatted according

to the formatting rules of address fields.

2-12 BYTES

<TP-PID> Protocol-Identifier. Values between

0-255.

1 BYTE

<TP-DCS> Data Coding Scheme. Values between

0-255.

1 BYTE

<TP-SCTS> The TP-Service-Center-Time-Stamp field

is given in semi-octet representation, and

represents the local time as described in

GSM03.40

7 BYTE

<TP-UDL> User data length 1 BYTE

<TP-UD> User data 0-140 BYTES

Table 3-55: +CMGR/+MMGR Parameters (Cont.)

<Parameter> Description
