Chapter 3: AT Commands Reference
April 15, 2008 G24-L AT Commands Reference Manual 3-297
The following table shows the +MPINGSTAT unsolicited response parameters.
Table 3-209: +MPINGSTAT Unsolicited Response Parameters
<Parameter> Description
<status> Specifies a status of ping request execution.
Defined values:
0 - The unsolicited response with this <status> will be
sent to DTE upon completion of ping request. If ping
request was aborted or socket connection was
terminated for any reason, this unsolicited response will
not be reported to DTE.
1 - The unsolicited response with this <status> will be
sent to DTE if no ICMP reply message was received
within timeout.
2 - The unsolicited response with this <status> will be
sent to DTE if socket connection was terminated for
any reason. This status essentially means that ping
request execution was aborted.
3 - Flow Control OFF. The unsolicited response with
this <status> will be sent to DTE if phone doesn't have
enough memory to process sending an Echo Request
message.
4 - Flow Control ON. The unsolicited response with
this <status> will be sent to DTE if phone has enough
memory to send an Echo Request message after flow
control was OFF.
<"Destination IP"> Specifies the target machine (computer) for ping
request, which is identified by IP address 4 octets long
in dotted decimal notation. Each octet of IP address has
valid value range of 0 to 255.
<SentMessages> Specifies a total number of sent Echo Request
messages.
<ReceivedMessages> Specifies a total number of received Echo Reply
messages corresponding to Echo Request messages.
<AvarageRTT> Specifies average Round Trip Time (RTT) for this ping
request. This value will be reported if and only if
<ReceivedMessages> value is greater than zero.
Calculation of this value comprises of accumulating all
RTT values and dividing total accumulated RTT by
<ReceivedMessages> value. Only an integral part of a
result will be reported and any digits of a fraction part
will be truncated.
