A - 4 MC9500-K Mobile Computer User Guide
RF Exposure USA: FCC Part 2, FCC OET Bulletin 65 Supplement C
Canada: RSS-102
EU: EN 50360
Japan: ARIB STD T56
Australia: Radio communications Standard 2003
EMI/RFI USA: FCC Part 15, Class B
Canada: ICES 003 Class B
EU: EN55022 Class B, EN55024, EN 301 489-1, EN 301 489-7, EN 301
489-17, EN 301 489-19, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN
50121-4
Australia: AS/NZS CISPR-22
Laser Safety IEC/Class 2/FDA Class ll in accordance with IEC60825-1/EN60825-1
Data Capture Specifications
Options 1D laser scanner
2D imager
1D laser scanner and color camera
2D imager and color camera
Linear 1D Scanner (SE950) Specifications
Optical Resolution 4mil minimum element width
Roll +/- 35° from vertical
Pitch Angle +/- 65° from normal
Skew Tolerance +/- 50° from normal
Ambient Light 10,000 ft. candles (107,640 Lux)
Shock 2,000 +/- 5% G
Scan Rate 104 (+/- 12) scans/sec (bidirectional)
Scan Angle 47° +/- 5° (typical); 35° +/- 3° reduced
2D Imager Engine (SE4500-SR) Specifications
Field of View Horizontal - 40°
Vertical - 25°
Optical Resolution 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light 9,000 ft. candles (96,900 Lux)
Table A-1
MC9500-K Technical Specifications (Continued)
Item Description
