1 - 4 MC9500-K Mobile Computer User Guide
Figure 1-3 Lift microSD Card Holder Door
4. Insert the microSD card into card holder door ensuring that the card slides into the holding tabs on each side of
the door.
Figure 1-4 Insert microSD Card in Holder
5. Close the card holder door and slide to the right to lock into place.
6. Align the SD card cover over the access hole and press down until it snaps into place.
Version 2
To install the microSD card:
1. Remove the SD card cover using the end of the stylus.
Figure 1-5 SD Card Cover Removal
2. Slide the microSD card holder door to the left to unlock.
3. Lift the microSD card holder door.
microSD Card Holder Door
microSD card
Holding tab
SD Card Cover
Stylus
